MCMB
Excellent in low-temperature and input-output performance
MCMB used as a negative electrode material for lithium-ion batteries is a type of artificial graphite that is heat-treated to obtain a pitch. The pitch is then used to extract mesophase as a solvent-extracted residue, which is then carbonized to form graphitized particles.
We handle a variety of grades of MCMB and provide products with superior low temperature and input/output characteristics to meet customer needs.
| 製品名 | 種類 | 形状 | 粒子径 D50 (μm) |
容量規格 mAh/g |
初期効率 ％ |
S.S.A ㎡/g |
Tap密度 g/cm3 |
備考 | |
|---|---|---|---|---|---|---|---|---|---|
| PG11 | MCMB | 球状 | 中 | 9～14 | ≧350 | ≧92 | ≦ 3.5 | ≧1.0 | |
| PG-11C | 中 | 11～16 | ≧350 | ≧93 | ≦ 3.0 | ≧1.2 | 炭素被膜処理 | ||
| PG13 | 大 | 16～20 | ≧360 | ≧94 | ≦ 3.0 | ≧1.2 | |||
| PG11A | 中 | 9～14 | ≧350 | ≧92 | ≦ 3.5 | ≧1.15 | 人造黒鉛添加 | ||
| PG13A | 大 | 16～20 | ≧360 | ≧94 | ≦ 3.0 | ≧1.2 | 人造黒鉛添加 | ||
| PS | 小 | 10～13 | ≧320 | ≧90 | ≦ 2.5 | ≧1.2 | |||
| PM | 中 | 15～19 | ≧325 | ≧92 | ≦ 1.5 | ≧1.25 | |||
| PL | 大 | 19～23 | ≧335 | ≧94 | ≦ 1.2 | ≧1.3 | |||
| PL-15 | 中 | 14～17 | ≧330 | ≧94 | ≦ 1.3 | ≧1.3 | |||
| PSH | 粉砕品 | 中 | 10～14 | ≧345 | ≧91 | ≦ 1.6 | ≧1.2 | ||
| PLH | 大 | 19～23 | ≧350 | ≧92 | ≦ 1.2 | ≧1.3 | |||
| PWSH | 小 | 8～12 | ≧345 | ≧93 | ≦ 3.5 | ≧1.2 | |||
| PWSH-05 | 極小 | 4～6 | － | － | ≦ 2.0 | ≧1.0 | |||
| ACP-H | 極小 | 5～8 | ≧340 | ≧92 | ≦ 2.0 | ≧1.0 | 炭素被膜処理 | ||
| PWSHC | 小 | 8～12 | ≧340 | ≧93 | ≦ 2.0 | ≧1.1 | 炭素被膜処理 | ||
| PW-6B | 球状 | 小 | 6～10 | ≧330 | ≧92 | ≦ 2.0 | ≧1.2 | ||
| PW-8A | 小 | 8～10 | ≧310 | ≧90 | ≦ 4.0 | ≧1.05 | 人造黒鉛添加 | ||
