NCM
High nickel content, small particle size(5μ～), High density grade.
|
Application： |
Electric tool, E-bike, Electric Vehicle (EV、HV、PHV) |
|
Composition： |
NCM523, NCM622, NCM811(Under R&D） |
| Grade | Nickel Content |
１C Specific Capacity (mAh/g) |
D50 (μm) |
BET (m2/g) |
Lifetime Property @80% |
Remarks |
|---|---|---|---|---|---|---|
| 203L | NCM523 (50%) | 154.5 | 11.29 |
0.28 |
≧1200cyc | In production |
| 203E | NCM523 (50%) | 153.5 | 11.18 | 0.25 | ≧1800cyc | |
| 203W | NCM523 (50%) | 153.3 | 11.13 | 0.3 | ≧2200cyc | |
| 206 | NCM622 (60%) | 159.3 | 13.25 | 0.25 | ≧500cyc | |
| 206L | NCM622 (60%) | 160.5 | 12.76 | 0.25 | ≧1200cyc |
※The above are representative values, not the lowest values of the specifications.
